Unlike standard heavy underwater cables that pull down ROV bodies and increase propulsion energy consumption, this Fathom ROV floating hybrid cable adopts precision density matching foam extrusion technology to achieve neutral buoyancy underwater. It perfectly matches the lightweight maneuverability design of Fathom observation-class ROVs, greatly reducing vehicle control resistance, avoiding cable tangling around reefs, pipelines and aquaculture facilities, and extending continuous underwater working time of Fathom ROV vehicles.

1. 2 Core Tinned Copper Power Conductors

   Low-resistance oxygen-free tinned copper, 0.5mm²~2.5mm² customizable cross-section, rated 300/500V, stable DC power output for Fathom ROV thrusters, cameras and onboard sensors. Cross-linked PE insulation resists seawater electrolytic corrosion and insulation breakdown under long-term hydrostatic pressure.

2. Single-Mode Fiber Optic Unit

   Embedded single-mode optical fiber bundle, supporting gigabit low-latency data transmission, real-time 4K underwater video, sonar signal, navigation SLAM and remote control command delivery, no signal attenuation within working depth range. Water-blocking gel filled fiber tube prevents seawater penetration to damage optical cores.

3. Central Aramid Kevlar Strength Member

   High-tensile Kevlar fiber reinforcement layer bears all pulling load during ROV deployment, recovery and fast navigation; power and fiber cores stay stress-free, breaking strength customizable from 100kg to 500kg to match different Fathom ROV model tonnage.

4. Zero Buoyancy PUR Foam Outer Jacket

   High-visibility yellow polyurethane foam sheath with balanced density close to seawater (1.03g/cm³), achieves full floating state underwater. Abrasion-resistant, anti-UV, salt-spray resistant, IP68 deep waterproof, withstands repeated winding on cable reels and frequent bending without cracking. Minimum bend radius only 6× cable outer diameter, ultra-flexible for narrow-space underwater inspection.

5. 3. Full Water-Blocking & Deep-Sea Reliability

   Every internal component is wrapped with water-blocking swellable fibers. Once the outer jacket is scratched by seabed rocks, the absorbent material expands instantly to block seawater infiltration, protecting copper power cores and optical fibers from short circuit or signal failure. Suitable for continuous long-hour underwater operation of Fathom ROV inspection missions.

   H3: 4. Ultra-Flexible & Anti-Torsion Construction

   Stranded ultra-fine copper conductors and torque-balanced cable structure support 720° repeated torsion without wire breakage. Perfect for Fathom ROV rotating camera and multi-angle underwater detection, no kinking or wire fatigue after thousands of bending cycles.

   H3: 5. Fully Customizable for All Fathom ROV Models

   H2: Main Application Scenarios for Fathom ROV 2-Core Floating Hybrid Cable

   This floating power fiber hybrid tether is the standard replacement and upgrade cable for all Fathom series observation ROV vehicles, widely used in subsea industries:

   H2: Complete Technical Specifications (SEO Data Section, Google Likes Structured Params)




   Item	Standard Parameter	Custom Options
   Product Name	2-Core Floating Hybrid Power Fiber Cable for Fathom ROV	Custom model code available
   Power Conductor	2×0.75mm² tinned copper	0.5–2.5mm²
   Optical Fiber	2-core single-mode fiber	1/4/6/8 fibers
   Rated Voltage	300/500V DC	600V upgrade
   Buoyancy Type	Neutrally floating (zero buoyancy)	Slightly positive buoyancy
   Outer Jacket	Foam PUR high-visibility yellow	Black, green customized
   Reinforcement	Kevlar aramid fiber	Dyneema high-strength fiber
   Breaking Tensile Strength	350lb (158kg)	100–500kg adjustable
   Waterproof Grade	IP68 deep submersible	Depth rated up to 500m
   Min. Bend Radius	6× cable OD	Special flexible version 4× OD
   Operating Temp	-20℃ ~ +60℃	Low-temperature cold-resistant variant
   Compliance	RoHS, CE marine standard	OEM test report & certification

1. Offshore wind farm underwater foundation inspection

2. Marine aquaculture cage net monitoring & fish stock survey

3. Dam, reservoir, river pipeline internal detection

4. Coastal port hull & underwater structure corrosion inspection

5. Underwater salvage, submerged target search with Fathom ROV camera

6. Scientific marine environmental sampling & underwater terrain mapping

7. Cable length: 50m, 100m, 200m, 300m, customized unlimited length

8. Power core cross-section: 0.75mm² / 1.0mm² / 1.5mm² / 2.0mm²

9. Fiber count: 1–8 single-mode fibers optional

10. Tensile strength, outer diameter, jacket color, connector matching (Binder 770, WetLink penetrator) support OEM modification to match Fathom original ROV tether interface

6. H2: Why Choose Our Hybrid Floating Cable Over Original Fathom ROV Tether

1. Cost-effective alternative matching Fathom ROV electrical & mechanical compatibility, lower MOQ than official original cable (100 meters minimum order)

2. Professional marine cable factory production, stable mass supply for ROV integrators, research institutions and marine engineering companies

3. One-stop supporting service: cable + matching underwater connectors + cable reel assembly technical guidance

4. Strict factory pressure, torsion, salt spray aging testing before delivery, 3-year product warranty

5. Fast lead time for standard stock lengths; custom specifications delivered within 7–15 working days

8. H2: Frequently Asked Questions (FAQ — Long-Tail Keyword Capture for Google Index)

9. Q1: Can this 2-core floating hybrid cable fully replace the original Fathom ROV tether?

10. A1: Yes. We match the electrical impedance, fiber transmission parameters and tensile load of factory Fathom ROV tethers. Connector pin assignment can be customized to directly plug-and-play with Fathom vehicle control units without circuit modification.

11. Q2: Is this floating hybrid cable suitable for both fresh water and seawater Fathom ROV operation?

12. A2: Absolutely. Tinned copper conductors and anti-corrosion PUR jacket resist seawater salt erosion, water-blocking structure works stably in lakes, reservoirs and ocean saltwater environments.

13. Q3: What maximum working depth can this Fathom ROV floating cable support?

14. A3: Standard model supports 0–300m underwater depth; we provide deep-water reinforced versions up to 500m operating depth upon request.

15. Q4: Can I order custom length and fiber counts for my Fathom ROV project?

16. A4: Full customization supported. Adjust power core size, fiber quantity, cable length, outer diameter and tensile strength according to your Fathom ROV power consumption and data transmission requirements.

17. H2: Conclusion

18. The 2-Core Floating Hybrid Power & Fiber Optic Cable for Fathom ROV Vehicles delivers integrated power supply and high-speed fiber communication with industry-leading neutral buoyancy performance. Solving core pain points of heavy drag, easy tangling and limited data bandwidth of traditional ROV cables, it becomes the ideal tether upgrade for Fathom underwater robots used in marine inspection, survey and engineering operations. Contact our marine cable engineering team to get customized technical drawings, sample testing and bulk order quotation for your Fathom ROV system today.
