Industrial Robot Cable
PUR Spiral Cable | High Flexible Retractable Coiled Spring Cable for Industrial Equipment
Specification
| Basic Structure | Conductor+Insulation+Jacket+Hose |
| Conductor | Plain Copper/ Tinned Copper |
| Insulation | PE |
| Braid | Kevlar/ Plain Copper/ Tinned Copper |
| Jacket | PUR/TPE/PCP |
INTRODUCTION
PUR spiral cable (also called coiled spring cable, retractable cable, or spiral power cord) is a high-flexible cable pre-wound into a helical spring shape and jacketed with polyurethane (PUR). It is engineered for industrial equipment that requires continuous extension, retraction, and reciprocating movement — delivering power and signal transmission while keeping the workspace tidy and preventing tangling.
A PUR spiral cable combines two proven technologies: a coiled spring structure that stretches and automatically retracts, and a polyurethane (PUR) jacket that protects against the toughest industrial conditions. The helix acts as a built-in strain relief and cable carrier, so the cable extends up to 3–4 times its unstretched length and springs back when tension is released. Compared with standard PVC or TPE coiled cords, the PUR jacket offers significantly higher wear resistance, oil resistance, and low-temperature flexibility, making it the preferred choice for demanding mobile equipment.
Abrasion resistance — PUR withstands repeated friction and scraping; its wear resistance is roughly 10× that of ordinary PVC, extending service life in dynamic applications.
Oil, chemical and solvent resistance — stable against mineral oils, greases, coolants and most industrial chemicals, ideal for machine shops and production floors.
Wide temperature range — typical working range of about -25 °C to +80 °C (special variants from -40 °C/-65 °C up to 105 °C), keeping flexibility in cold environments.
Water, UV and hydrolysis resistance — suitable for indoor and outdoor use.
High restoring force & anti-tangle — the spring shape pulls the cable back automatically, reducing entanglement and trip hazards.
表格
| Feature | Benefit |
|---|---|
| Retractable helix | Extends to 3–4× coiled length, self-retracts when released |
| Built-in strain relief | Reduces stress at cable ends and terminations |
| Space-saving | Short storage length in compact machinery enclosures |
| High flex endurance | Designed for millions of bending/extending cycles |
| Shielding options | Tinned copper braid/spiral shield for signal integrity |
表格
| Parameter | Typical Value |
|---|---|
| Rated voltage | 300/300 V, 300/500 V (industrial models up to 600 V) |
| Working temperature | -25 °C to +80 °C (options to -65 °C / 105 °C) |
| Test voltage | 1,000 – 2,000 V AC |
| Conductor | Fine-stranded bare or tinned copper (high flexibility) |
| Insulation | PP / PE / TPE / XLPE |
| Jacket | Polyurethane (PUR), halogen-free options available |
| Extension ratio | 3:1 to 4:1 |
| Standards | VDE, GB, UL (e.g., UL 758 AWM, UL 21293) |
Values vary by core count, conductor size and customer specification — always confirm the datasheet for your application.
PUR spiral cables are widely used wherever equipment moves repeatedly:
Robotic arms and manipulators — power, control and sensor connections for continuous motion
CNC machine tools and processing equipment
Automated production lines, conveyors and logistics systems
Cranes, lifting platforms and hoists
Retractable reels, handheld tools and portable instruments
Agricultural machinery, construction machinery and trucks
Shanghai Deru Cable (上海德汝电缆) manufactures PUR spiral cables to your exact requirements: core count (2–30+), conductor cross-section (e.g., 0.14–2.5 mm² / AWG 28–14), coiled length and extended length, shield or unshielded construction, jacket color, and connector/harness assembly. OEM and custom specifications are available for robotics, automation and export projects.
Q: What is the difference between a spiral cable and a coiled cable?A: They refer to the same product type — a cable pre-formed into a helical spring shape that extends and retracts. "Spring cable," "coiled cord" and "retractable cable" are common synonyms.
Q: Why is PUR better than PVC for spiral cables?A: PUR provides much higher abrasion resistance (about 10× PVC), superior oil/chemical resistance and better low-temperature flexibility, which means longer life in harsh industrial environments.
Q: Can PUR spiral cables be used outdoors?A: Yes. The PUR jacket resists water, UV radiation and hydrolysis, making it suitable for both indoor and outdoor applications.
Q: How much can a PUR spiral cable extend?A: Typically 3 to 4 times its unstretched coiled length, depending on the helix design and core configuration.
Contact Shanghai Deru Cable for a free engineering review and quotation for your PUR spiral cable project.
ADVANTAGES
FAQ
Q: Is Derul Cable the original manufacturer?
A: Derul Cable is a special cable manufacturer. Our factory is based in Shanghai.
Q: Is the price negotiable?
A: Yes, the price is negotiable. Our price is also flexible due to several factors including purchase quantity.
Q: What is the regular MOQ for your cable?
A: Any quantity is okay to purchase for product at stock. For product with no stock, its MOQ is usually 100-200 meters per type.
Q: How can I get sample?
A: Usually you only need to pay the express freight, and after your confirmation of the product dimension and structure, we can arrange the sample and send it directly to you.
Q: Is OEM or ODM service available?
A: OEM and ODM services are both available. You can provide us with your requirement for the product and we will evaluate it to push forward.
Q: What is the regular production time?
A: For regular quantity, it usually costs about 15-25 days to produce.
